Bảng tra cứu kích thước ren hệ inch - tiêu chuẩn UNEF
17-1-2017Nominal | Major | Major | Tapping | TPI | Pitch |
N 12 - 32 UNEF | 0.216 | 5.486 | 4.80 | 32 | 0.794 |
1/4" - 32 UNEF | 0.250 | 6.350 | 5.70 | 32 | 0.794 |
5/16" - 32 UNEF | 0.313 | 7.938 | 7.25 | 32 | 0.794 |
3/8" - 32 UNEF | 0.375 | 9.525 | 8.85 | 32 | 0.794 |
7/16" - 28 UNEF | 0.438 | 11.112 | 10.35 | 28 | 0.907 |
1/2" - 28 UNEF | 0.500 | 12.700 | 11.80 | 28 | 0.907 |
9/16" - 24 UNEF | 0.563 | 14.288 | 13.40 | 24 | 1.058 |
5/8" - 24 UNEF | 0.625 | 15.875 | 15.00 | 24 | 1.058 |
11/16" - 24 UNEF | 0.688 | 17.462 | 16.60 | 24 | 1.058 |
3/4" - 20 UNEF | 0.750 | 19.050 | 18.00 | 20 | 1.270 |
13/16" - 20 UNEF | 0.813 | 20.638 | 19.60 | 20 | 1.270 |
7/8" - 20 UNEF | 0.875 | 22.225 | 21.15 | 20 | 1.270 |
15/16" - 20 UNEF | 0.938 | 23.812 | 22.70 | 20 | 1.270 |
1" - 20 UNEF | 1.000 | 25.400 | 24.30 | 20 | 1.270 |
1 1/16" - 18 UNEF | 1.063 | 26.988 | 25.80 | 18 | 1.411 |
1 1/8" - 18 UNEF | 1.125 | 28.575 | 27.35 | 18 | 1.411 |
1 1/4" - 18 UNEF | 1.250 | 31.750 | 30.55 | 18 | 1.411 |
1 5/16" - 18 UNEF | 1.313 | 33.338 | 32.10 | 18 | 1.411 |
1 3/8" - 18 UNEF | 1.375 | 34.925 | 33.70 | 18 | 1.411 |
1 7/16" - 18 UNEF | 1.438 | 36.512 | 35.30 | 18 | 1.411 |
1 1/2" - 18 UNEF | 1.500 | 38.100 | 36.90 | 18 | 1.411 |
1 9/16" - 18 UNEF | 1.563 | 39.688 | 38.55 | 18 | 1.411 |
1 5/8" - 18 UNEF | 1.625 | 41.275 | 40.10 | 18 | 1.411 |
1 11/16" - 18 UNEF | 1.688 | 42.862 | 41.60 | 18 | 1.411 |
